Build a Vulnerable IIS SharePoint Lab with Fluent Bit: Complete Deployment Guide

A full step-by-step guide with all scripts to deploy a vulnerable SharePoint-style site on Windows IIS and ship its logs with Fluent Bit —…

Andrey Pautov

~12 min read · February 13, 2026 (Updated: February 13, 2026) · Free: No

A full step-by-step guide with all scripts to deploy a vulnerable SharePoint-style site on Windows IIS and ship its logs with Fluent Bit — from scratch.

Introduction

Most people learn IIS and "SharePoint" pentesting the hard way: in production, under pressure, with incomplete logs, and with zero room to break things. That's backwards.

If you want to become effective at web pentesting (or detection engineering) you need a repeatable lab that you can reset, attack, and observe — over and over — until patterns become instinct. Not "a random vulnerable VM," but a realistic stack that mirrors what you'll actually meet in enterprise environments:

Windows Server + IIS (classic target surface)
SharePoint-style app patterns (auth-less pages, legacy ASP.NET, messy inputs)
Attack scenarios that generate teachable telemetry (XSS, traversal, SQLi-like payloads)
Proper logging coverage so every request leaves evidence: access logs, kernel-level rejects, deep diagnostics, and Windows events
Centralized shipping so you train the real workflow: attack → logs → search/hunt → detection rules

That's exactly what this guide gives you.

You'll build a fully automated vulnerable IIS lab (Windows Server 2012 R2 in Vagrant) with a purposely insecure "SharePoint-style" ASP.NET site, and you'll instrument it with Fluent Bit as a Windows service to forward IIS W3C, HTTPERR, Failed Request Tracing, ULS-style app logs, and Windows Event Logs to an HTTP backend (like XPLG or any listener).

Why this matters for pentest training:

You don't just "get a payload to work" — you learn what success and failure look like in logs.
You can practice real reporting: reproduce, capture evidence, explain impact, map telemetry.
Blue team? Same lab becomes your detection range: write queries, build alerts, validate them against known traffic.
You can reset fast and iterate: infrastructure-as-lab beats "pet VMs" every time.

The goal is simple: turn pentesting practice into an engineering loop — controlled exploits, consistent telemetry, and repeatable experiments — so you build skill that transfers directly to real environments.

What You'll Build

Windows Server 2012 R2 VM (Vagrant + libvirt/VirtualBox)
IIS with W3C logging, Failed Request Tracing
Vulnerable SharePoint app — XSS, path traversal, SQLi simulation (all requests logged)
Fluent Bit — Windows service collecting IIS + Windows Event logs, shipping to HTTP backend

If you like this research, buy me a coffee (PayPal) — Keep the lab running

Introduction
Prerequisites
Project Structure
1. Vagrantfile
2. Provisioning Script: enable-rdp.ps1
3. Provisioning Script: install-iis.ps1
4. Provisioning Script: install-sharepoint.ps1
5. Provisioning Script: install-fluent-bit.ps1
6. Vulnerable SharePoint App
7. IIS Log Types: Access vs Error
8. Fluent Bit Config: fluent-bit.conf
9. Fluent Bit Parsers: parsers.conf
Deployment Steps

Prerequisites

Vagrant 2.2+
libvirt + vagrant-libvirt (or VirtualBox)
FreeRDP (freerdp2-x11)

sudo apt install vagrant libvirt-daemon-system libvirt-clients qemu-kvm vagrant-libvirt freerdp2-x11
sudo usermod -aG libvirt $USER
# Log out and back in

Project Structure

Create the following layout:

Windows_IIS/
├── Vagrantfile
├── fluent-bit/
│   ├── fluent-bit.conf
│   └── parsers.conf
├── vulnerable-sharepoint/
│   ├── default.aspx
│   ├── search.aspx
│   ├── documents.aspx
│   ├── api.aspx
│   └── Web.config
└── provisioning/
    ├── enable-rdp.ps1
    ├── install-iis.ps1
    ├── install-sharepoint.ps1
    └── install-fluent-bit.ps1

1. Vagrantfile

# Windows IIS + SharePoint Foundation VM (vulnerable, for logging training)
# Uses pre-built Windows Server 2012 R2 box. For custom build from ISO, see docs/PACKER_FROM_ISO.md
# ISO reference: /home/andrey/DC_simulator/iso/Windows_Server_2012_R2_Evaluation.iso

Vagrant.configure("2") do |config|
  config.vm.box = "jborean93/WindowsServer2012R2"
  config.vm.box_version = "1.1.0"
  config.vm.guest = :windows
  config.vm.communicator = "winrm"
  config.winrm.username = "vagrant"
  config.winrm.password = "vagrant"

  config.vm.provider "virtualbox" do |vb|
    vb.name = "windows-iis-sharepoint"
    vb.memory = 4096
    vb.cpus = 2
    vb.customize ["modifyvm", :id, "--vram", "64"]
  end

  config.vm.provider "libvirt" do |lv|
    lv.memory = 4096
    lv.cpus = 2
    lv.management_network_name = "default"
  end

  # Private network: VM gets 192.168.56.10, host is 192.168.56.1 (VirtualBox) or virbr0 (libvirt)
  # Fluent Bit will send to host (log-listener, XPLG) at this IP
  config.vm.network "private_network", ip: "192.168.56.10"

  # Upload fluent-bit config (avoids synced folder issues)
  config.vm.provision "file", source: "fluent-bit/fluent-bit.conf", destination: "C:/tmp/fluent-bit.conf"
  config.vm.provision "file", source: "fluent-bit/parsers.conf", destination: "C:/tmp/parsers.conf"

  # Upload vulnerable SharePoint app
  config.vm.provision "file", source: "vulnerable-sharepoint/default.aspx", destination: "C:/tmp/vulnerable-sharepoint/default.aspx"
  config.vm.provision "file", source: "vulnerable-sharepoint/search.aspx", destination: "C:/tmp/vulnerable-sharepoint/search.aspx"
  config.vm.provision "file", source: "vulnerable-sharepoint/documents.aspx", destination: "C:/tmp/vulnerable-sharepoint/documents.aspx"
  config.vm.provision "file", source: "vulnerable-sharepoint/api.aspx", destination: "C:/tmp/vulnerable-sharepoint/api.aspx"
  config.vm.provision "file", source: "vulnerable-sharepoint/Web.config", destination: "C:/tmp/vulnerable-sharepoint/Web.config"

  # Provision: enable RDP first, then IIS, SharePoint (with vulnerable app), Fluent Bit
  config.vm.provision "shell", path: "provisioning/enable-rdp.ps1", privileged: false
  config.vm.provision "shell", path: "provisioning/install-iis.ps1", privileged: false
  config.vm.provision "shell", path: "provisioning/install-sharepoint.ps1", privileged: true
  config.vm.provision "shell", path: "provisioning/install-fluent-bit.ps1", privileged: false, args: ["C:/tmp"]
end

2. Provisioning Script: enable-rdp.ps1

enable-rdp.ps1
# Enable RDP and open firewall for Remote Desktop
$ErrorActionPreference = "Stop"
Write-Host "Enabling Remote Desktop..."
Set-ItemProperty -Path "HKLM:\System\CurrentControlSet\Control\Terminal Server" -Name "fDenyTSConnections" -Value 0 -Force
Set-ItemProperty -Path "HKLM:\System\CurrentControlSet\Control\Terminal Server\WinStations\RDP-Tcp" -Name "UserAuthentication" -Value 0 -Force
Write-Host "Opening firewall for RDP..."
Enable-NetFirewallRule -DisplayGroup "Remote Desktop"
New-NetFirewallRule -DisplayName "RDP" -Direction Inbound -Protocol TCP -LocalPort 3389 -Action Allow -ErrorAction SilentlyContinue
Write-Host "RDP enabled. Restart required for some settings - or connect now."
Restart-Service TermService -Force -ErrorAction SilentlyContinue

3. Provisioning Script: install-iis.ps1

install-iis.ps1
# Install IIS with common features (vulnerable config for training)
$ErrorActionPreference = "Stop"
Write-Host "Installing IIS and Web features..."
Install-WindowsFeature -Name Web-Server -IncludeManagementTools
Install-WindowsFeature -Name Web-ASP-Net45
Install-WindowsFeature -Name Web-Net-Ext45
Install-WindowsFeature -Name Web-ISAPI-Ext
Install-WindowsFeature -Name Web-ISAPI-Filter
Install-WindowsFeature -Name Web-Log-Libraries
Install-WindowsFeature -Name Web-Request-Monitor
Install-WindowsFeature -Name Web-Http-Tracing
Install-WindowsFeature -Name Web-Stat-Compression
Install-WindowsFeature -Name Web-Dyn-Compression
Import-Module WebAdministration
Set-ItemProperty "IIS:\Sites\Default Web Site" -Name logFile.logFormat -Value "W3C"
Set-ItemProperty "IIS:\Sites\Default Web Site" -Name logFile.logExtFileFlags -Value "Date,Time,ClientIP,UserName,ServerIP,Method,UriStem,UriQuery,HttpStatus,Win32Status,TimeTaken,ServerPort,UserAgent,Referer"
Set-ItemProperty "IIS:\Sites\Default Web Site" -Name logFile.directory -Value "C:\inetpub\logs\LogFiles"
$content = @"
<!DOCTYPE html>
<html>
<head><title>SharePoint-style Site</title></head>
<body>
<h1>Simple SharePoint-style Landing</h1>
<p>This is a minimal IIS site for logging training. Vulnerable configuration.</p>
<p>Time: $(Get-Date)</p>
</body>
</html>
"@
$content | Out-File -FilePath "C:\inetpub\wwwroot\default.aspx" -Encoding UTF8
New-Item -ItemType Directory -Force -Path "C:\inetpub\logs\LogFiles" | Out-Null
New-Item -ItemType Directory -Force -Path "C:\inetpub\logs\FailedReqLogFiles" | Out-Null
Write-Host "IIS installation complete."

4. Provisioning Script: install-sharepoint.ps1

install-sharepoint.ps1
# Vulnerable SharePoint-style setup - precompiles to avoid ASP.NET temp folder permission issues
$ErrorActionPreference = "Stop"
Import-Module WebAdministration
if (-not (Test-Path "IIS:\AppPools\SharePointAppPool")) {
    New-WebAppPool -Name "SharePointAppPool"
    Set-ItemProperty "IIS:\AppPools\SharePointAppPool" -Name "managedRuntimeVersion" -Value "v4.0"
}
$sitePath = "C:\inetpub\wwwroot\SharePointSite"
$stagingPath = "C:\inetpub\wwwroot\SharePointStaging"
$vulnSource = $null
if (Test-Path "C:\vagrant\vulnerable-sharepoint\default.aspx") { $vulnSource = "C:\vagrant\vulnerable-sharepoint" }
elseif (Test-Path "C:\tmp\vulnerable-sharepoint\default.aspx") { $vulnSource = "C:\tmp\vulnerable-sharepoint" }
if ($vulnSource) {
    Write-Host "Deploying and precompiling vulnerable SharePoint app..."
    if (Test-Path $stagingPath) { Remove-Item -Path $stagingPath -Recurse -Force }
    New-Item -ItemType Directory -Force -Path $stagingPath | Out-Null
    Copy-Item -Path "$vulnSource\*" -Destination $stagingPath -Recurse -Force
    if (Test-Path $sitePath) { Remove-Item -Path "$sitePath\*" -Recurse -Force }
    New-Item -ItemType Directory -Force -Path $sitePath | Out-Null
    & "$env:SystemRoot\Microsoft.NET\Framework64\v4.0.30319\aspnet_compiler.exe" -p $stagingPath -v / -fixednames $sitePath
    Remove-Item -Path $stagingPath -Recurse -Force -ErrorAction SilentlyContinue
    Write-Host "Vulnerable app precompiled and deployed."
} else {
    Write-Host "Vulnerable app not found, creating placeholder..."
    $pageContent = @"
<!DOCTYPE html>
<html><head><title>SharePoint</title></head>
<body><h1>SharePoint-style Site</h1><p>Placeholder.</p></body>
</html>
"@
    $pageContent | Out-File -FilePath "$sitePath\default.aspx" -Encoding UTF8
}
$acl = Get-Acl $sitePath
$rule = New-Object System.Security.AccessControl.FileSystemAccessRule("IIS AppPool\SharePointAppPool", "Read", "ContainerInherit,ObjectInherit", "None", "Allow")
$acl.SetAccessRule($rule)
Set-Acl $sitePath $acl
$siteName = "SharePointSite"
if (-not (Test-Path "IIS:\Sites\$siteName")) {
    New-Website -Name $siteName -PhysicalPath $sitePath -ApplicationPool "SharePointAppPool" -Port 8080
    Write-Host "SharePoint site created on port 8080."
} else {
    Set-ItemProperty "IIS:\Sites\$siteName" -Name physicalPath -Value $sitePath
}
$ulsPath = "C:\Program Files\Common Files\Microsoft Shared\Web Server Extensions\15\LOGS"
New-Item -ItemType Directory -Force -Path $ulsPath | Out-Null
"# SharePoint ULS-style log - $(Get-Date)" | Out-File "$ulsPath\uls.log" -Encoding UTF8
Write-Host "SharePoint-style setup complete."

5. Provisioning Script: install-fluent-bit.ps1

# Install Fluent Bit on Windows - downloads from packages.fluentbit.io, installs as service
$ErrorActionPreference = "Stop"
[Net.ServicePointManager]::SecurityProtocol = [Net.SecurityProtocolType]::Tls12
$fluentBitVersion = "4.2.2"
$fluentBitUrl = "https://packages.fluentbit.io/windows/fluent-bit-$fluentBitVersion-win64.zip"
$installDir = "C:\fluent-bit"
$configDir = "$installDir\conf"
Write-Host "Installing Fluent Bit $fluentBitVersion..."
New-Item -ItemType Directory -Force -Path $installDir | Out-Null
New-Item -ItemType Directory -Force -Path "$installDir\data" | Out-Null
New-Item -ItemType Directory -Force -Path "$installDir\data\chunks" | Out-Null
New-Item -ItemType Directory -Force -Path $configDir | Out-Null
$zipPath = "$env:TEMP\fluent-bit-$fluentBitVersion-win64.zip"
if (-not (Test-Path $zipPath)) {
    Write-Host "Downloading Fluent Bit..."
    Invoke-WebRequest -Uri $fluentBitUrl -OutFile $zipPath -UseBasicParsing
}
$svc = Get-Service -Name "fluent-bit" -ErrorAction SilentlyContinue
if ($svc -and $svc.Status -eq "Running") {
    Stop-Service fluent-bit -Force
    Start-Sleep -Seconds 2
}
Write-Host "Extracting Fluent Bit..."
$extractDir = "$env:TEMP\fluent-bit-extract"
if (Test-Path $extractDir) { Remove-Item -Path $extractDir -Recurse -Force }
Add-Type -AssemblyName System.IO.Compression.FileSystem
[System.IO.Compression.ZipFile]::ExtractToDirectory($zipPath, $extractDir)
$extractedDir = Get-ChildItem -Path $extractDir -Directory | Where-Object { $_.Name -like "fluent-bit*" } | Select-Object -First 1
if ($extractedDir) {
    Get-ChildItem -Path $extractedDir.FullName | ForEach-Object {
        $dest = Join-Path $installDir $_.Name
        if (Test-Path $dest) { Remove-Item -Path $dest -Recurse -Force }
        Move-Item -Path $_.FullName -Destination $installDir -Force
    }
    Remove-Item -Path $extractDir -Recurse -Force -ErrorAction SilentlyContinue
}
$configSource = $args[0]
if (-not $configSource) { $configSource = "C:\tmp" }
if (Test-Path (Join-Path $configSource "fluent-bit.conf")) {
    Copy-Item (Join-Path $configSource "fluent-bit.conf") -Destination $configDir -Force
    Copy-Item (Join-Path $configSource "parsers.conf") -Destination $configDir -Force
    Write-Host "Config copied from $configSource"
} else {
    Write-Host "ERROR: fluent-bit config not found"
    exit 1
}
$fluentBitExe = Join-Path $installDir "bin\fluent-bit.exe"
$configPath = Join-Path $configDir "fluent-bit.conf"
if (Test-Path $fluentBitExe) {
    $binPath = "$fluentBitExe -c $configPath"
    $existing = Get-Service -Name "fluent-bit" -ErrorAction SilentlyContinue
    if ($existing) {
        sc.exe delete fluent-bit
        Start-Sleep -Seconds 2
    }
    sc.exe create fluent-bit binpath= $binPath start= auto
    Write-Host "Fluent Bit installed as Windows service."
    Start-Service fluent-bit -ErrorAction SilentlyContinue
} else {
    Write-Host "WARNING: fluent-bit.exe not found."
}
Write-Host "Fluent Bit installation complete."

6. Vulnerable SharePoint App

default.aspx

default.aspx
<%@ Page Language="C#" %>
<!DOCTYPE html>
<html>
<head><title>Vulnerable SharePoint - Logging Training</title></head>
<body>
<h1>Vulnerable SharePoint Site</h1>
<p>Intentionally vulnerable for security and logging training. All activity is logged.</p>
<ul>
<li><a href="default.aspx">Home</a></li>
<li><a href="search.aspx">Search (XSS)</a></li>
<li><a href="documents.aspx">Documents (Path Traversal)</a></li>
<li><a href="api.aspx">API (SQLi simulation)</a></li>
</ul>
<p>Request at: <%= DateTime.Now %></p>
</body>
</html>

search.aspx (Reflected XSS)

search.aspx
<%@ Page Language="C#" %>
<!DOCTYPE html>
<html>
<head><title>Search - Vulnerable SharePoint</title></head>
<body>
<h1>Document Search</h1>
<form method="GET" action="search.aspx">
  <input type="text" name="q" value="<%= Request.QueryString["q"] ?? "" %>" />
  <input type="submit" value="Search" />
</form>
<% if (!string.IsNullOrEmpty(Request.QueryString["q"])) { %>
  <p>Results for: <%= Request.QueryString["q"] %></p>
  <p><em>Vulnerable: reflected XSS in search - payload appears in response</em></p>
<% } %>
<p><a href="default.aspx">Back</a></p>
</body>
</html>

documents.aspx (Path Traversal)

documents.aspx
<%@ Page Language="C#" %>
<!DOCTYPE html>
<html>
<head><title>Documents - Vulnerable SharePoint</title></head>
<body>
<h1>Document Library</h1>
<form method="GET" action="documents.aspx">
  <label>File: <input type="text" name="file" value="<%= Request.QueryString["file"] ?? "report.pdf" %>" /></label>
  <input type="submit" value="Open" />
</form>
<%
string file = Request.QueryString["file"];
if (!string.IsNullOrEmpty(file)) {
  bool looksSuspicious = file.Contains("..") || file.Contains(":");
  Response.Write("<p>Requested file: " + Server.HtmlEncode(file) + "</p>");
  if (looksSuspicious) {
    Response.Write("<p><strong>Path traversal attempt detected - logged!</strong></p>");
  }
  Response.Write("<p><em>Vulnerable: path traversal attempts are logged for analysis</em></p>");
}
%>
<p><a href="default.aspx">Back</a></p>
</body>
</html>

api.aspx (SQLi Simulation)

api.aspx
<%@ Page Language="C#" %>
<%@ Import Namespace="System.Data" %>
<!DOCTYPE html>
<html>
<head><title>API - Vulnerable SharePoint</title></head>
<body>
<h1>REST API (SQLi simulation)</h1>
<form method="GET" action="api.aspx">
  <label>User ID: <input type="text" name="id" value="<%= Request.QueryString["id"] ?? "1" %>" /></label>
  <input type="submit" value="Query" />
</form>
<%
string id = Request.QueryString["id"];
if (!string.IsNullOrEmpty(id)) {
  string fakeQuery = "SELECT * FROM users WHERE id='" + id + "'";
  Response.Write("<p>Simulated query (logged): " + Server.HtmlEncode(fakeQuery) + "</p>");
  Response.Write("<p><em>Vulnerable: SQL injection - try id=1' OR '1'='1</em></p>");
}
%>
<p><a href="default.aspx">Back</a></p>
</body>
</html>

Web.config

Web.config
<?xml version="1.0" encoding="utf-8"?>
<configuration>
  <system.web>
    <compilation debug="true" targetFramework="4.5" tempDirectory="C:\inetpub\temp\ASP.NET" />
    <httpRuntime targetFramework="4.5" />
  </system.web>
</configuration>

7. IIS Log Types: Access vs Error

This topic explains each log type collected by Fluent Bit and whether it is an access log (successful requests) or an error log (failures, rejections, diagnostics).

Access Logs

IIS W3C Extended Log (iis.w3c)

Type: Access log Path: C:\inetpub\logs\LogFiles\W3SVC*/*.log Format: W3C Extended Log Format (space-separated)

Records every HTTP request that reaches IIS, whether it succeeds or fails from the application's perspective. Each line typically includes:

Use case: Traffic analysis, security auditing, performance, debugging. You see all requests, including 4xx/5xx responses.

Note: W3C logs include both successful (2xx) and failed (4xx, 5xx) requests. "Access" here means "request log," not "success-only."

Error Logs

HTTPERR (iis.httperr)

Type: Error log Path: C:\Windows\System32\LogFiles\HTTPERR\*.log Format: Space-separated

Records events where HTTP.sys (kernel-mode HTTP driver) rejects or fails requests before they reach IIS. Typical cases:

Connection timeouts
Rejected connections (e.g. too many)
Invalid requests
SSL/TLS handshake failures
Request header/body issues

Example events:

Timer_ConnectionIdle — client idle timeout
Timer_MinBytesPerSecond — slow client
Rejected — connection rejected
SSL handshake — TLS errors

Use case: Diagnosing connection and low-level HTTP issues that never reach the application.

Failed Request Tracing (iis.freb)

Type: Error / diagnostic log Path: C:\inetpub\logs\FailedReqLogFiles\*\*.xml Format: XML

Generated when Failed Request Tracing is enabled for a site. Contains detailed diagnostics for requests that meet failure rules (e.g. status 500, slow requests).

Contents:

Request details
Module trace (which module failed)
Stack traces
Timing

Use case: Deep troubleshooting of specific failing requests. Must be enabled per-site in IIS.

Application Logs

SharePoint ULS (sharepoint.uls)

Type: Application log Path: C:\Program Files\Common Files\Microsoft Shared\Web Server Extensions\15\LOGS\*.log Format: Tab-separated

SharePoint Unified Logging Service logs. Contains application-level events, errors, and traces from SharePoint.

Use case: SharePoint-specific debugging and monitoring. Only present if SharePoint (or a similar structure) is installed.

Windows Event Log — Application (windows.application)

Type: System / application log Source: Windows Event Log API Channel: Application

System and application events from the Application channel, including IIS and ASP.NET.

Use case: Service starts/stops, application crashes, and other system-level events.

Summary: Access vs Error

Access logs = what was requested (W3C). Error logs = what failed and why (HTTPERR, FREB, ULS, Event Log).

8. Fluent Bit Config: fluent-bit.conf

fluent-bit.conf
# Fluent Bit for Windows IIS - raw collection, NO log modifications
# Outputs logs as-is from each source. Adjust Host/Port in [OUTPUT] for your backend.

[SERVICE]
    Flush         2
    Grace         30
    Log_Level     info
    Parsers_File  parsers.conf
    storage.path  C:/fluent-bit/data/chunks
    storage.sync  normal

# --- ACCESS LOGS ---

# IIS W3C Extended Log (access log)
# Path: C:\inetpub\logs\LogFiles\W3SVC*/*.log
# Tag: iis.w3c
[INPUT]
    Name              tail
    Tag               iis.w3c
    Path              C:/inetpub/logs/LogFiles/W3SVC*/*.log
    Parser            iis_w3c
    Path_Key          source_path
    DB                C:/fluent-bit/data/flb_iis.db
    Mem_Buf_Limit     5MB
    Refresh_Interval  10
    Ignore_Older      1h
    Read_from_Head    On

# --- ERROR LOGS ---

# HTTPERR (HTTP.sys error log)
# Path: C:\Windows\System32\LogFiles\HTTPERR\*.log
# Tag: iis.httperr
[INPUT]
    Name              tail
    Tag               iis.httperr
    Path              C:/Windows/System32/LogFiles/HTTPERR/*.log
    Parser            iis_httperr
    DB                C:/fluent-bit/data/flb_httperr.db
    Mem_Buf_Limit     2MB
    Refresh_Interval  10
    Ignore_Older      1h
    Read_from_Head    On

# Failed Request Tracing (diagnostic XML)
# Path: C:\inetpub\logs\FailedReqLogFiles\*\*.xml
# Tag: iis.freb
[INPUT]
    Name              tail
    Tag               iis.freb
    Path              C:/inetpub/logs/FailedReqLogFiles/*/*.xml
    Parser            iis_freb
    DB                C:/fluent-bit/data/flb_freb.db
    Mem_Buf_Limit     2MB
    Refresh_Interval  10
    Ignore_Older      1h
    Read_from_Head    On

# --- SHAREPOINT / APPLICATION ---

# SharePoint ULS (Unified Logging Service)
# Path: ...\Web Server Extensions\15\LOGS\*.log
# Tag: sharepoint.uls
[INPUT]
    Name              tail
    Tag               sharepoint.uls
    Path              C:/Program Files/Common Files/Microsoft Shared/Web Server Extensions/15/LOGS/*.log
    Parser            sharepoint_uls
    DB                C:/fluent-bit/data/flb_uls.db
    Mem_Buf_Limit     5MB
    Refresh_Interval  10
    Ignore_Older      1h
    Read_from_Head    On
    Path_Key          source_path

# Windows Event Log - Application channel
# Tag: windows.application
[INPUT]
    Name              winlog
    Tag               windows.application
    Channels         Application
    Interval_Sec      5

# --- FILTERS: separate logs by type for XPLG (cluster_name->source->host) ---

[FILTER]
    Name    modify
    Match   iis.w3c
    Add     cluster_name windows-iis-vm
    Add     source       iis_w3c
    Add     log_type     access

[FILTER]
    Name    modify
    Match   iis.httperr
    Add     cluster_name windows-iis-vm
    Add     source       iis_httperr
    Add     log_type     error

[FILTER]
    Name    modify
    Match   iis.freb
    Add     cluster_name windows-iis-vm
    Add     source       iis_freb
    Add     log_type     error

[FILTER]
    Name    modify
    Match   sharepoint.uls
    Add     cluster_name windows-iis-vm
    Add     source       sharepoint_uls
    Add     log_type     application

[FILTER]
    Name    modify
    Match   windows.application
    Add     cluster_name windows-iis-vm
    Add     source       windows_event
    Add     log_type     system

# Normalize message field (XPLG expects message for display)
[FILTER]
    Name    modify
    Match   iis.*
    Rename  log message

[FILTER]
    Name    modify
    Match   sharepoint.*
    Rename  log message

[FILTER]
    Name    modify
    Match   windows.*
    Rename  Message message

# Ensure "log" field for XPLG (many collectors use "log" as primary display)
[FILTER]
    Name    modify
    Match   *
    Copy    message log

# --- OUTPUT ---

[OUTPUT]
    Name            http
    Match           *
    Host            192.168.56.1
    Port            8081
    URI             /ingest
    Format          json_stream
    Json_date_key   timestamp
    Json_date_format iso8601

[OUTPUT]
    Name                http
    Match               *
    Host                192.168.56.1
    Port                30303
    URI                 /logeye/api/logger.jsp?token=b757c1af-2664-4c90-adf5-1a58fa1bf2ab
    Format              json
    Json_date_key       time
    Json_date_format    iso8601
    Retry_Limit         5
    Header              X-Xpolog-Sender fluent-bit-windows-iis
Note: Change Host and Port in [OUTPUT] to your log backend. 192.168.56.1 is the host on the Vagrant private network.

9. Fluent Bit Parsers: parsers.conf

parsers.conf
[PARSER]
    Name        iis_w3c
    Format      regex
    Regex       ^(?<date>\d{4}-\d{2}-\d{2}) (?<time>\d{2}:\d{2}:\d{2}) (?<log>.*)$
    Time_Key    time
    Time_Format %H:%M:%S
    Time_Keep   On
[PARSER]
    Name        iis_w3c_header
    Format      regex
    Regex       ^#(?<log>.*)$
    Time_Keep   Off
[PARSER]
    Name        iis_httperr
    Format      regex
    Regex       ^(?<date>\d{4}-\d{2}-\d{2}) (?<time>\d{2}:\d{2}:\d{2}\.\d+) (?<c_ip>[^ ]+) (?<cs_method>[^ ]+) (?<cs_uri_stem>[^ ]+) (?<sc_status>[^ ]+) (?<s_port>[^ ]+) (?<cs_referer>[^ ]+) (?<cs_user_agent>[^ ]+)
    Time_Key    time
    Time_Format %H:%M:%S
    Time_Keep   On
[PARSER]
    Name        iis_freb
    Format      regex
    Regex       ^(?<log>.*)$
    Time_Keep   Off
[PARSER]
    Name        sharepoint_uls
    Format      regex
    Regex       ^(?<timestamp>\d{2}/\d{2}/\d{4} \d{2}:\d{2}:\d{2}\.\d+)\s+(?<log>.*)$
    Time_Key    timestamp
    Time_Format %m/%d/%Y %H:%M:%S
    Time_Keep   On

Deployment Steps

1. Create the directory structure and files

mkdir -p Windows_IIS/{fluent-bit,vulnerable-sharepoint,provisioning}
cd Windows_IIS

Create each file above (Vagrantfile, provisioning scripts, ASPX pages, configs).

2. Start the VM

# With libvirt:
sg libvirt -c "vagrant up"
# With VirtualBox:
vagrant up

First run: 15–30 minutes (downloads Windows box ~4–5 GB, provisions).

3. Connect and test

vagrant rdp
# Credentials: vagrant / vagrant

In the VM browser: http://localhost:8080/

Vulnerable URLs:

http://192.168.56.10:8080/search.aspx?q=<script>alert(1)</script>
http://192.168.56.10:8080/documents.aspx?file=../../../etc/passwd
http://192.168.56.10:8080/api.aspx?id=1' OR '1'='1

4. Ensure log backend is reachable

Run a log collector on the host (e.g. port 8081) so Fluent Bit can send logs. The VM reaches the host at 192.168.56.1.

Andrey Pautov

If you like this research, buy me a coffee (PayPal) — Keep the lab running

#windows #sharepoint #laboratory #cybersecurity #penetration-testing

Build a Vulnerable IIS SharePoint Lab with Fluent Bit: Complete Deployment Guide

A full step-by-step guide with all scripts to deploy a vulnerable SharePoint-style site on Windows IIS and ship its logs with Fluent Bit —…

A full step-by-step guide with all scripts to deploy a vulnerable SharePoint-style site on Windows IIS and ship its logs with Fluent Bit — from scratch.

Introduction

What You'll Build

If you like this research, buy me a coffee (PayPal) — Keep the lab running

Table of Contents

Prerequisites

Project Structure

1. Vagrantfile

2. Provisioning Script: enable-rdp.ps1

3. Provisioning Script: install-iis.ps1

4. Provisioning Script: install-sharepoint.ps1

5. Provisioning Script: install-fluent-bit.ps1

6. Vulnerable SharePoint App

default.aspx

search.aspx (Reflected XSS)

documents.aspx (Path Traversal)

api.aspx (SQLi Simulation)

Web.config

7. IIS Log Types: Access vs Error

Access Logs

Error Logs

Failed Request Tracing (iis.freb)

Application Logs

Windows Event Log — Application (windows.application)

Summary: Access vs Error

8. Fluent Bit Config: fluent-bit.conf

9. Fluent Bit Parsers: parsers.conf

Deployment Steps

1. Create the directory structure and files

2. Start the VM

3. Connect and test

4. Ensure log backend is reachable

Andrey Pautov

If you like this research, buy me a coffee (PayPal) — Keep the lab running

Reporting a Problem
