OneDrive API Integration Using Microsoft Graph: A Developer Notes Version
OneDrive integration sounds simple until you actually start building it.
Satva Solutions
2 min read
At first, you think the work is only about uploading a file or reading a folder.
But the real setup starts earlier: app registration, Graph permissions, OAuth, access tokens, refresh tokens, and then OneDrive file APIs.
That is the part most developers should understand before touching the upload code.
The first thing to know
OneDrive APIs are handled through the Microsoft Graph API.
So you are not only connecting to "OneDrive."
You are registering an app in Microsoft Entra and then using Graph endpoints to work with OneDrive files.
The flow usually looks like this: Register app → Add permissions → Complete OAuth → Get token → Call OneDrive APIs
Once this base is correct, file upload, folder creation, file listing, deletion, and version handling become much easier.
Start with app registration
Create an app registration in Microsoft Entra.
This gives you the basic details your integration needs:
Client ID
Client Secret
Tenant ID
Redirect URIClient ID
Client Secret
Tenant ID
Redirect URIThe redirect URI matters a lot.
Microsoft sends the user back to this URL after login and consent. If the redirect URI in Microsoft Entra and the redirect URI in your OAuth request do not match exactly, authentication will fail.
This is one of the most common setup mistakes.
Add privileges based on your use case
For most user-based OneDrive integrations, delegated permissions are used. That means a user signs in, gives consent, and your app works with the files that the user can access.
Common permissions include:
User. Read
Files.ReadWrite.All
Sites.Read.All
offline_accessUser. Read
Files.ReadWrite.All
Sites.Read.All
offline_accessA small note here: Do not add permissions randomly. Add only what your integration actually needs.
For example, if the app only uploads files for a signed-in user, delegated file access may be enough. If the app needs tenant wide background access, that becomes a different setup and usually needs admin consent.
OAuth comes before file upload
Before uploading anything, your app needs a valid access token.
The basic OAuth flow is:
- User signs in
- User gives consent
- Microsoft returns authorization code
- Backend exchanges code for access token
- App uses token to call Graph API
Every OneDrive API request needs this token in the header:
Authorization: Bearer {access_token}Authorization: Bearer {access_token}Access tokens expire, so refresh token handling should be added if the app needs long-running access or background sync.
This is where offline_access becomes important.
After that, start with small API calls
Do not start with a complex upload flow first. Start by checking whether authentication is working.
For example:
GET /me/driveGET /me/driveNext list files:
GET /me/drive/root/childrenGET /me/drive/root/childrenOnce these calls work, move to file upload, folder creation, delete, move, copy, or version handling.
For small files, direct upload is usually fine. For large files, use an upload session so the file can be uploaded in chunks.
Common issues developers hit
Most OneDrive API problems come from setup mistakes.
Here are the ones that usually waste time:
Redirect URI does not match
Permission is missing
Admin consent is not granted
Access token is expired
Client secret is wrong or expired
offline_access is missing
Refresh token is not handled properlyRedirect URI does not match
Permission is missing
Admin consent is not granted
Access token is expired
Client secret is wrong or expired
offline_access is missing
Refresh token is not handled properlySo before debugging the upload code, check the app registration, permissions, token response, and request headers first.
Final note
OneDrive API integration becomes much easier when the foundation is clear. The file operations are not the hard part.
The real work is getting Microsoft Entra app registration, Graph permissions, OAuth, and token handling right.
Once that is done, Microsoft Graph gives a clean way to upload files, create folders, list documents, manage versions, and build file sync features inside your application.
